DRAYTEK VIGOR AP 912C

SKU: 4712909129015

Manufacturer: DRAYTEK

802.11ac PoE Access Point for ceiling. Supports 8 SSID’s, WDS and Roaming. Built in RADIUS Server and AP Management.

Download

VigorAP 912C ceiling-mount wireless access point is ideal for hospitalities, small offices and small campus. They support stand-alone operation and can also integrate with DrayTek routers or VigorACS platform for central management. They are designed to provide a smooth wireless connection by supporting 802.11ac standard and providing advanced features, such as AirTime Fairness, Band Steering, and AP-Assisted Roaming.

Concurrent Dual-band 802.11ac with 2x2 MIMO
Plug-n-Play Meshing
1 x PoE-capable Gigabit Ethernet port
AirTime Fairness and Band Steering
AP-Assisted Roaming
Built-in RADIUS server for 802.1x authentication
Compliant with Vigor central AP management and VigorACS

Overview
Specifications

Concurrent Dual-band 802.11ac with 2x2 MIMO
Plug-n-Play Meshing
1 x PoE-capable Gigabit Ethernet port
AirTime Fairness and Band Steering
AP-Assisted Roaming
Built-in RADIUS server for 802.1x authentication
Compliant with Vigor central AP management and VigorACS

Products specifications

Indoor/Outdoor	Indoor
Bands	2.4 & 5GHz (802.11ac Wave 2)
PoE	Yes
LAN ports	1 x GbE
Operation Mode	AP, Mesh Root, Mesh Node, Range Extender
Multiple Subnet	-
MIMO	2 x 2
Antennas	2 x Internal PiFA DB
Max. Number of SSID	8 (4 per band)
Max. Number of Connective Clients	256 (128 per band)
Roaming	Yes
Band Steering	Yes
AirTime Fairness	Yes
Built-in RADIUS	Yes
USB port	No
AP management	Yes
PoE Out	No

Products specifications

Indoor/Outdoor	Indoor
Bands	2.4 & 5GHz (802.11ac Wave 2)
PoE	Yes
LAN ports	1 x GbE
Operation Mode	AP, Mesh Root, Mesh Node, Range Extender
Multiple Subnet	-
MIMO	2 x 2
Antennas	2 x Internal PiFA DB
Max. Number of SSID	8 (4 per band)
Max. Number of Connective Clients	256 (128 per band)
Roaming	Yes
Band Steering	Yes
AirTime Fairness	Yes
Built-in RADIUS	Yes
USB port	No
AP management	Yes
PoE Out	No
